The VBOX Optima includes the existing functionality of the VBOX Classic as well as a KVM Switch that facilitates Lights Out Remote Support to PC based systems.

VBOX Optima

Product Specification

  • VBOX with 3rd party non-corporate Internet access to provide Managed Virtual Layer 2 VPN
  • VBOX with Integrated Internet accessible IP KVM (if Ethernet is not supported  by PC system)
  • Layer 2 Network connectivity through 2 or more preconfigured VBOX units over WiFi/Hotspot/LAN
  • Encrypted Connections
  • Lights out Remote Support -  KVM
    • Allows access to PC systems with no Ethernet connectivity with a VNC Viewer (Internet Browser)
    • Alternative to Engineer coming on site for troubleshooting system boot issues
    • Alternative to onsite vendor support for systems with no Ethernet connectivity
    • KVM Encrypted Username/Password access
  • Ports include:
    • 1 x DHCP Client
    • 1 x VLAN (Layer2)
    • 1 x HDMI (in)
    • 1 x HDMI (out)
    • 1 x USB - (Mouse + KYBD)
    • Adapaters supplied for various interfaces - DVI, VGA, DisplayPort for Video and PS/2 (Keyboard use only).
  • Power Mains (110-240Vac)
  • Weight: 6.5kg
  • Dimensions (W X D X H) mm: 411 x 323 x 168
  • Portable Robust Case
